FILL-RITE 820 SERIES
Recommended Flow Range: 2 to 20 GPM ( 7.6 to 75.7 LPM)
Maximum Pressure: 120 PSIG ( 8.2 Bars) at 70° F ( 21° C)
: 50 PSIG ( 3.4 Bars) at 130° F ( 54° C)
Temperature: Minimum Operating - 0° F ( -17.8° C)
: Maximum Operating - 130° F ( 54.4° C)
Accuracy± 0.5% Using Calibration Factor
± 0.2% Using Liquid Calibration
Units of Measure: Ounces, Pints, Quarts, Liters and Gallons. ( Special
calibration options also available.)
Range 9999 Current Total
10, 000, 000 Accumulated Total
FILL RITE 800 SERIES
Features: 3 Wheel Mechanical Flow Meter
Accuracy: ± 1%
Flow Rate: 5 to 20 GPM ( 19 to 76 LPM )
Pressure rating ( PSI ) : 50 ( 3.4 bar )
Resetable cumulative totalizer : 99.9 Gallons / 999 Liter
Master totalizer: 99, 999.9 Gallons / 999, 999 Liter
Construction: Aluminium
Large easy to read numbers: Yes
Plexible ports for horizontal or vertical positioning: Yes
360° Positionable Ports : -
Approvals: UL/ CSA Listed
20 Calibration Settings : -
Powered by two AA batteries: -
Gallon or liter Registration: Yes
Painted black for instalation on eitherHeavy Duty Standard Duty pumps except FR4210 ; comes with all fitting : Yes
1 " Ports: Yes
1-½ " Ports: -
Gravity-flow strainer straps tank contaminants: Yes
BSP threads; Yes
SAE threads: -
Teflon or nickel coatings increase selection of compatible fluids: Yes
Compatible fluids: Diesel Fuel, gasoline, kerosene, mineral spirits, stoddard solvent and heptane
FILL RITE 900 SERIES
Features: 4 Wheel Mechanical Flow Meter
Accuracy: ± 2%
Flow Rate: 6 to 40 GPM ( 20 to 151 LPM )
Pressure rating ( PSI ) : 50 ( 3.4 bar )
Resetable cumulative totalizer: 999.9 Gallons / 9, 999 Liter
Master totalizer: 999, 999.9 Gallons / 9, 999, 999 Liter
Construction: Aluminium
Large easy to read numbers: Yes
Plexible ports for horizontal or vertical positioning: Yes
360° Positionable Ports : -
Approvals: UL/ CSA Listed
20 Calibration Settings : -
Powered by two AA batteries: -
Gallon or liter Registration: Yes
Painted black for instalation on eitherHeavy Duty Standard Duty pumps except FR4210 ; comes with all fitting :
1 " Ports:
1-½ " Ports: Yes
Gravity-flow strainer straps tank contaminants: -
BSP threads; Yes
SAE threads:
Teflon or nickel coatings increase selection of compatible fluids: Yes
Compatible fluids: Diesel Fuel, gasoline, kerosene, mineral spirits, stoddard solvent and heptane
